Laser cu deplasare in camp magnetic, mult mai fiabil fata de cele uzuale.
Se vinde impreuna cu telecomanda si cablul de alimentare.
Suna excelent!
Poze reale. Ce vedeti e ce primiti!
Specificatii:
The compact disk player which adopted virtual battery operation, and advanced MASH and 1-bit DAC.
Virtual battery operation is adopted as a power-source part. This power circuit is a circuitry developed using the property of MOS-FET to the maximum extent, and high-quality sound-ization is attained by cutting the wraparound of the noise from a power source or a digital circuit.
In order to reduce the ill effect to the tone quality by the oscillation from the outside, the newly developed THCB vibration proof design is adopted. With this structure, the external oscillation is cut with an effective combination of a steel plate and a viscoelasticity object.
Newly developed advanced MASH and 1-bit DAC are adopted as a D-A-conversion part. By the differential circuit of 8 DAC stream compositions, the noise component was cut and high S N, the low distortion, and the high linearity are realized. Moreover, the high order accuracy and the high fidelity play are investigated by adopting as a differential circuit the instrumentation circuitry currently used for the measuring instrument etc.
The digital servo is adopted. In this circuitry, the fluence of an electric current is stopped to the minimum by adjusting to the amount of servoes which was proper and was stabilized according to the condition of compact disk, and the ripple of a servo electric current is decreased.
SL1 is carried in the loading mechanism. The product made from TNRC excellent in the periodic-damping property was adopted as the disk tray, and the original swing arm drive system has realized the smooth operation.
The class AA circuitry is adopted as a lineout circuitry, and the faithful waveform transmission which is not influenced by the load intensity is realized.
The high-quality sound carbon film resistor which used the non-magnetic-material cap is adopted as a resistor. Moreover, high-quality sound-ization is attained by adopting an electrolytic capacitor and the polypropylene capacitor for audios.
The digital optical output-terminal is carried.
Gilding is given to the line-output termination.
The display-device mode functionality in which a display-device window can be switched off is carried, and function-logic-diagram window noise can be stopped.
Technical data:
Channel number 2, stereophonic 20,000 Hz frequency response 2, + -0.3 dB Signal to Noise Ratio 118dB Harmonic distortion 0.0015% (1kHz, 0dB) Channel separation 110dB Flutter-Below the measurability -D-A converter S-Advanced MASH 1bit Headphone Out 15mW 32Ohm Power Consumption 17W
Power Supply 230-240V, 50 60HZ Dimensions WxHxD 430x125x335mm Weight 6.3 kg
